alright so a little while ago i got clear corner lenses on my 2000 totyota corolla, well the stock ugly orange led lights were the next thing to go, so i got clear leds that light up amber, so now my turn signal flashes a lot faster then it should, i bout load resistors but while looking at the wiring harness i saw 3 wires, i have no idea which ones to hook it up to, there was a white/black, green/black, and a green.. i already hooked one resistor up to the green/black/green as a guess and it didn't work..

any help would be appreciated =]

Could just try buzzing out the connector end with a multimeter. Find the side that runs to gronud and the hot side. Shouldn't really matter which end you connect the load resister to, as it only needs to load that circuit. I remember seeing a Black/White, Green/Black, and Green/Yellow - don't remember a solid green one - but then again, it also depends on if the car is NUMMI, TMMC, or Japan made.

Took bad you couldn't wire the load resister directly to the bulb base itself - hacking up the main wiring, even if you take precautions (cut the right wire, heatshrink, seal, etc.) always invites an electrical headache down the road.

Tridon EP35 flasher relay.
